Viscount Legend One 73 Stage Keyboard

Viscount Legend One 73 Stage Keyboard

The Legend ONE is the ultimate portable all-in-one keyboard created by Viscount International. Based on the powerful Legend Soul Engine, it features 3 additional sound zones for a total of 4 sound sections: Organ, Sound 1, Sound 2, Pedals.The new alternative sounds are easy to use thanks to the twin Sound 1 and Sound 2 sections, which also includes beautiful new Acoustic and Electric Pianos, Synths, Strings and much more!Two models are available: The Legend ONE 61 has the waterfall keyboard and weighs only 10kg (22 lbs) while the Legend ONE 73 has a semiweighted waterfall keyboard and weighs only 11,5 kg (25 lbs).We paid the highest attention to the design, using only solid wood and metal, to produce a long-lasting organ dedicated to all kinds of stages.

• 73-key (E-E) Semi-weighted keyboard
• Touch Curve: 4 curves + 1 Fixed
• Keyboard Mode: Single, Split, Dual
• Transpose: +/- 6 semitones
• Octave: +/- 2 octave
• Technology: TMT (Tonewheel Modeling Technology)+ HDS (High definition sampling)
• Parts: 3 Fully independent (Upper, Lower, Pedals)
• Sound Sections: 4 independent layers (Organ, Sound1, Sound2, Pedals)
• Power Supply: AC100/240V

SPECIFICATIONS

• Keyboard:
  • 73-Key (E-E) Semi-Weighted Keyboard
• Touch Sensitivity: 4 Touch Curves + 1 Fixed
• Keyboard Mode: Single, Split, Dual
• Sound Generator:
  • Technology: TMT (Tonewheel Modeling Technology) + HDS (High Definition Sampling)
  • Effects: Includes Vibrato/Chorus and Rotary Speaker, plus 3 independent assignable effect slots with effects such as Tremolo, Vibrato, Chorus, Flanger, Phaser, Wah, Ring Modulator, Delay, EQ, Compression, Amplifiers, Master Reverb, and 3-Band Master EQ
• Preset: 396 Programs (99 Banks x 4 Programs)
• Sounds: 4 Independent Layers (Organ, Sound1, Sound2, Pedals)
• Polyphony: 240
• Transposer: -6 +5 Semitones
• Fine Tuning: 427.5 Hz – 452.9 Hz (+/- 50 Cents)
• Organ Models:
  • BC (1938), C3 (1955), B3 (1967), BC (1936), B3 (1956), A100 (1961)
  • Baroque Pipe, Romantic Pipe, Symph Pipe, Farf Organ, Vx Organ
• Pedals Sustain: On/Off, Decay Control
• Harmonic Percussion: On/Off, Volume Soft/Normal, Decay Fast/Slow, Harmonic 2nd/3rd, Volume Control, Decay Control
• Effects:
  • Vibrato / Chorus: Upper On/Off, Lower & Pedal On/Off, V1 / V2 / V3 / C1 / C2 / C3 Selector
  • Rotary / Amp: On/Off, Fast/Slow/Stop, Drive, 8 Presets + 1 Custom
  • Reverb: 13 Reverb Types
  • Additional Effects: 2 Insert (IFX1, IFX2) + 1 Master (MFX), 14 Effect Types, 108 Effect Presets
  • Master EQ: 3-Band (Low, Mid, High) With Programmable Parameters
  • Ac. Piano String Resonance: Yes
  • Ac. Piano Damper Resonance: Yes
  • Overdrive: Quantity Control of the Distortion on the Rotary / Amp Effect
• Interface:
  • Drawbars – Upper: 2 Sets of Nine Drawbars (16′, 5 1/3′, 8′, 4′, 2 2/3′, 2′, 1 3/5′, 1 1/3′, 1′)
  • Data Memory: 396 Programs (99 Banks x 4 Programs)
  • MIDI: In, Out with Soft-Thru Option, Pedalboard In, MIDI on USB
• Other:
  • Colours and Finishes: Satin Black, Red Walnut
  • Dimensions (W x H x D): 73-Keys: 108.9 x 32.8 x 11.1 cm / 42.87 x 12.91 x 4.37 in
  • Weight:
    • 73-Keys: 11.6 kg / 25.57 lbs
    • 61-Keys: 10 kg / 22.05 lbs

Manufacturer:Viscount Organs
Model:9A13LEGENDONE73
SKU:I814791-N-5-WHXB
