RCF L15P400 Low Frequency Replacement Woofer – 15 Inch

Get Low Distortion With the RCF L15P400 Low Frequency Replacement Woofer – 15 Inch

Incredibly linear frequency response characteristics, extreme high power handling while generating the lowest harmonic distortion of any comparable 15-inch transducer within its application range. The L15P400 uses a fiber loaded cone assembly along with a high excursion triple roll surround. This combination provides remarkable strength and a peak to peak maximum excursion of 52mm. The T-pole also features RCF Precision’s spaced gap demodulation technology, progressively braking the voice coil, providing a much smoother transition for the moving mass as it reaches its maximum excursion limits. Forced air venting system.

• 4-inch, fiberglass inside/outside copper voice coil
• 1600 W continuous program power handling
• 97 dB Sensitivity
• 30 Hz 1.5 kHz Frequency range
• Aluminum demodulation ring
• Forced air ventilation and 14 mm top plate for minimum power compression
• Dual spider design with silicon based dampening control
• Triple-roll surround and corrugated straight cone geometry

SPECIFICATIONS

• Nominal Diameter: 15 inch / 381 mm
• Program Power: 1600 W
• Sensitivity: 97 dB
• Effective Piston Diameter: 240 / 13.39
• Minimum Impedance: 6.3 ohms
• Voice Coil Winding Material: Copper
• Number of Layers: 2
• Top Plate Thickness: 14 mm / .55 inch
• Surround Material: Polycotton
• Magnets: Ceramic
• Spider Dual: With silicon based damping control
• Rated Impedance: 8 ohm
• Power Handling Capacity: 800 W
• Frequency Range: 30 – 1500 Hz
• Max. Excursion Before Damage: 50 mm / 1.97 inch
• Voice Coil Diameter: 4 inch
• Voice Coil Length: 23 mm / .91 inch
• Kind of Layers: Inside / outside
• Cone Design: Straight
• Surround Design: Triple roll
• Dual-Force Air Ventilation: Yes

Thiele – Small Parameters

• Resonance Frequency (FS): 36 Hz
• Mechanical Factor: 7.50
• Total Factor: .25 Qts
• Effective Moving Mass (MMS): 150 G
• Effective Piston Area (SD): .09 m2
• Voice Coil Inductance at 1 KHz (LE1K): 1.20 mH
• DC Resistance (RE): 4.8 ohm
• Electrical Factor (QES): .27 Qes
• BL Factor (BL): 24.8 T x m
• Equivalent Cas Air Loaded (VAS): 160 liters
• Max. Linear Excursion (XMAX): 8 mm
• Half-Space Efficiency (EFF): 2.6 %

Mounting Information

• Overall Diameter: 393 mm / 15.47
• Bolt Hole Diameter: 7 mm / .28 inch
• Rear Mount Baffle Cut-Out: 360 mm / 14.17
• Bolt Circle Diameter: 371-376 mm / 14.61-14.8
• Front Mount Baffle Cut-Out: 352 mm / 13.86
• Volume Occupied by the Driver: 4.3 liters / .17 ft

Standard Compliance

• CE Marking: Yes

Size

• Weight: 13.5 kg / 29.76 pounds
• Diameter: 393 mm / 15.47 inches
• Height: 159 mm / 6.26

Shipping Information

• Package Width: 420 mm / 16.54 inches
• Package Height: 195 mm / 7.68
• Package Weight: 15.5 kg / 34.17
• Package Depth: 425 mm / 16.73

Manufacturer:RCF
Model:L15P400
SKU:I431698-3-WHXB
