The New Benchmark For Cost-Effective Power Amplification – The Powersoft T304 4-Channel Power Amplifier
Customer Return Like New (Box & Contents Included)
The T Series is a very flexible and cost-effective amplifier platform with loudspeaker processor. All models deliver the same high peak voltage allowing high SPL with single 8/16 ohm cabinets on all models. The high voltage is also good for sharing power between the channels for applications such as bi-amped loudspeakers or subwoofers with passive tops.
The amplifiers feature input via Dante, AES3 and analog. The Dante and AES3 solutions are optimized for daisy-chained distribution of 2-channel audio for distribution to many amplifiers without the need for external switches/repeaters/ splitters. A simple Dante system has a daisy chain with the mixing console at one end, a WiFi access point at the other end and the amplifiers in-between. MyPowersoft services are available for this product.
- The loudspeaker processing sets a new benchmark for cost-effective amplification for small and medium-sized systems and stage monitors. The T Series can be controlled and configured in different ways
- Full control with a PC running Armona
- Control from the front panel display for features like preset recall (also per output), gain, delay, mute. This makes it very easy to use for small systems in a rental company. The display also shows the available headroom with easy to read numbers in dB as well as other status monitoring parameters
- Web app. Use any device with a browser (e.g. a tablet) and access the amplifier via an external WiFi access point for easy control
- Group controllable advanced EQ with raised cosine filters
- Large preset library
- Preset compatibility with X Series
- Very long FIR filters (42.6 ms)
- Control and monitoring through ArmonaPlus
SPECIFICATIONS
General
- Output Power per Channel: 750W @ 2 , 750 W @ 4 , 750 W @ 8
- Bridge Mode Output Power: 1500 W @ 4 , 1500 W @ 8
- Max Unclipped Output Voltage @8 : 145 V peak
- Current: 50 A peak
- Thermal Dissipation (1/8 of max output power @ 4 )
- 120 V: 537 BTU/h -135.3 kcal/h
- 230 V: 512 BTU/h -129.0 kcal/h
AC Main Power
- Power Supply: Universal, regulated switch mode with PFC (Power Factor Correction)
- Nominal Power Requirement: 100-240 V 10%, 50-60 Hz
- Operating Voltage: 90 V 264 V
- Power Consumption/Current Draw (1/8 of max output power @ 4 )
- 120 V: 537 W 4.7 A
- 230 V: 525 W 2.7 A
Audio
- Gain: 32dB
- Input sensitivity: 2.57 Vrms
- Max input level: 24 dBu
- Frequency response: 20 Hz – 20 kHz ( 0.5 dB) @ 1 W, 8 Ohm
- S/N ratio: greater than 110 dB (20 Hz – 20 kHz, A weighted)
- Crosstalk separation: less than -70 dB @ 1kHz
- THD+N: less than 0.1% (typical less than 0.5%)
- IMD: less than 0.1% (typical less than 0.5%)
- Input impedance: 20 k balanced
DSP
- AD Converter: 24 Bit Tandem @ 48 kHz 125 dB-A Dynamic Range – 0.005 % THD+N
- DA Converter: 24 Bit Tandem @ 48 kHz 117 dB-A Dynamic Range – 0.003 % THD+N
- Memory/Presets: 256 MB (RAM) plus 512 MB flash for presets
- Input Equalizer: Raised-cosine, custom FIR, parametric IIR: peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass
- Crossover: Linear phase (FIR), Butterworth, Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR)
- Delay: 2 s (input) + 100 ms (output) for time alignment
- Limiters: TruePower, RMS voltage, RMS current, Peak limiter
- Damping Control: Active Damping Control and Live Impedance measurement
Construction
- Dimensions (L x H x W): 19.1 in x 1.8 in x 16.0 in (484 mm x 44.45 mm x 405 mm)
- Weight: 15.7 lbs (7.1 kg)
Manufacturer:Powersoft Audio
Model:T304
SKU:I588483-GA20260209A-3-WHXE
