The Empire 36″ TahoeLUXURY DVX36FP Series Direct Vent Fireplace models retain the same overall dimensions as Premium models, but feature ceramic glass (for better heat transfer), a dimmer-controlled accent lamp inside the fireplace, a automatic blower, and an intricately detailed 13-piece log set atop the Slope Glaze Excess Burner for a fuller ember bed. The larger flame also means that more heat is produced.
Luxury models are offered in Millivolt (with standing pilot), Intermittent Pilot and in Multi-Function remote models.
Our Green Earth Preferred IP and Multi-Function remote models eliminate the standing pilot for greater efficiency and hugeenergy savings.
The Multi-Function remote control option automatically varies flame height and blower speed to maintain your pre-set temperature. If there’s a power outage, these models can operate with a standing pilot to provide uninterrupted heating.
Features:
- Empire slope glaze excess burner system
- Millivolt ignition – standing pilot
- Manual variable flame height
- Remote ready
- Variable speed thermostatic blower
- Dimmable accent lighting
- Ceramic firebrick liner (style optional)
- Black Louvers
- Electrical junction box included for hook up
- Ceramic glass
- Control panel located behind lower louvers
Burner and Log Specifications:
- Empire slope glaze excess burner system
- Ember bed
- Millivolt ignition – standing pilot
- Manual variable flame height
- Remote ready
- 13 Piece ceramic fiber log set
- Manufactured for indoor use
Venting Specifications:
- Top vent only
- Requires 4″ x 6 5/8″ venting
- Approved for installation with Simpson Dura Vent
- Venting materials are not provided with this appliance and must be purchased separately
- Please be sure to check with the manufacturers installation guide for venting solutions
- Please note that a 25% restocking fee applies to all returned venting products
Product Specifications:
- Fuel Type: Gas
- Vent Type: Direct Vent
- Vent Size: 4×6-5/8
- Ignition Type: Electronic or Millivolt or Electronic Ignition with Multi-Function Remote
- Installation Type: Zero Clearance
- Style: Traditional
- Vent Inner Diameter: 4 Inches
- Vent Outer Diameter: 6-5/8 Inches
- Weight: 156 lbs.
- Model: Natural Gas (NG) / Propane (LP)
- Max. (BTU/HR): 35,000 BTU’s (NG) / 30,000 BTU’s (LP)
- Min. (BTU/HR): 24,500 BTU’s (NG) / 21,000 BTU’s (LP)
Dimensions:
Actual Dimensions:
- Height: 40 3/4″
- Width: 39″
- Depth: 19 7/8″
Framing Dimensions:
- Height: 40 7/8″
- Width: 39 3/8″
- Depth: 19 7/8″
ModelNumbers:
- DVX36FP31LN(Natural Gas, Millivolt)
- DVX36FP71LN (Natural Gas, Intermittent Pilot)
- DVX36FP91LN (Natural Gas, Multi-Function (MF) Control)
- DVX36FP31LP(Liquid Propane, Millivolt)
- DVX36FP71LP (Liquid Propane, Intermittent Pilot)
- DVX36FP91LP (Liquid Propane, Multi-Function (MF) Control)
